MZ 500 D-Drive
CNC Gear Hobbing Machine

32 DP
Max Pitch Rating
12,000
RPM Hob Speed
7
CNC Axes
High-speed (12,000 rpm) direct-drive hob head with CNC shifting.
Synchronous high-speed (6,000 rpm) direct-drive work and tailstock spindles:
Programmable clamping pressure.
Flexible dialogue programming.
Cast iron and steel base optimized for dynamic stability.
Flexible automation systems.
Pneumatic deburring unit.
Bolstering your quality and productivity.
The MZ 500 D-drive CNC gear hobbing machine from Monnier + Zahner offers optimized hobbing of ultra-fine and fine-pitch spur gears in a compact package.
Automation options for the MZ 500 D-Drive
Each option below can be configured for this machine to match your part, batch size, and cell layout. Our applications team will help you choose the right setup.
Gantry Loader
Gravity Magazine
Bowl Feeder
Industrial Robot
Cobot

MZ 500 D-Drive
Technical Specifications


Metric / Imperial
Max Pitch Rating
0.60 mn / 42.33 DP
Max Workpiece Diameter
40 mm / 1.575 in
Max Workpiece Diameter (auto-load)
30 mm / 1.181 in
Max Workpiece Length
60 mm / 2.362 in
Max Workpiece Length (auto-load)
60 mm / 2.362 in
Cutter Head Radial Travel
54 mm / 2.126 in
Min. Radial Position of Cutter Head
0.60 mn / 42.33 DP
Max. Radial Position of Cutter Head
54 mm / 2.126 in
Max. Work Spindle Speed
4,000 rpm
Max. Spindle Speed
12,000 rpm
Max. Hob Diameter
32 mm / 1.26 in
Max. Cutter Width
35 mm / 1.378 in
Max. Cutter Shift
30 mm / 1.181 in
Width
2,280 mm / 89.76 in
Depth
1,800 mm / 70.87 in
Height
2,200 mm / 86.61 in
Weight
1,300 kg / 2,900 lb
Electrical Connection
220V, 3 phase, 60 Hz
